mcx::drive::SwitchOnDisabled Class Reference
Inheritance diagram for mcx::drive::SwitchOnDisabled:
Inheritance graph
[legend]
Collaboration diagram for mcx::drive::SwitchOnDisabled:
Collaboration graph
[legend]

Public Member Functions

 SwitchOnDisabled (Cia402FsmData &data)

void enter () override

void iterate (double time) override

state_machine::EventStatus gotoDisengage () override

state_machine::EventStatus gotoEngage () override

- Public Member Functions inherited from mcx::drive::Cia402FsmBase
 Cia402FsmBase (Cia402FsmData &)

void registerUserEvents () override

virtual state_machine::EventStatus shutdown (int state_id)

virtual state_machine::EventStatus switchOn (int state_id)

virtual state_machine::EventStatus disableVoltage (int state_id)

virtual state_machine::EventStatus quickStop (int state_id)

virtual state_machine::EventStatus disableOperation (int state_id)

virtual state_machine::EventStatus enableOperation (int state_id)

virtual state_machine::EventStatus resetting (int state_id)

virtual state_machine::EventStatus gotoOff ()

virtual state_machine::EventStatus gotoQuickStop ()

virtual state_machine::EventStatus gotoModeAction ()

virtual state_machine::EventStatus faultAcknowledge ()

virtual state_machine::EventStatus switchMode (DriveMode drive_mode, const std::string &machine_name)

state_machine::EventStatus warning_ (const mcx::state_machine::Error &error) override

state_machine::EventStatus forcedDisengaged_ (const mcx::state_machine::Error &error) override

state_machine::EventStatus shutdown_ (const mcx::state_machine::Error &error) override

state_machine::EventStatus emergencyStop_ (const mcx::state_machine::Error &error) override

- Public Member Functions inherited from mcx::state_machine::State< Cia402FsmBase >
virtual const char * stateName () const

void create (MACHINE *newMachine, const STATE &state, int id, ErrorHandleBase *errorHandle)

void addErrorsHelper (ErrorGroup *stateErrors, const ErrorGroup &errorsToAdd)

void enableErrorsHelper (ErrorGroup *stateErrors, const ErrorGroup &refErrors, const ErrorGroup &errorsToAdd)

void disableErrorsHelper (ErrorGroup *stateErrors, const ErrorGroup &errorsToAdd)

void addErrors (const ErrorGroup &codes, signal_monitor::MonitorAction newAction)

void setMachine (MACHINE *newMachine)

MACHINE * getMachine ()

double getDtSec () const

int id ()

void clearEventQueue (bool highPriority=true, bool lowPriority=true)

Cia402FsmBase * setActiveState (int state_id)

NEWSTATE * setActiveState ()

NEWSTATE * setActiveState (const NEWSTATE &state)

bool isStateActive ()

bool isStateActive (int id)

void addEvent (const Event0< Cia402FsmBase > &event, double timeoutSec=EVENT_DEFAULT_TIMEOUT_SEC, EventPriority priority=HIGH_PRIORITY_EVENT)

void addEvent (const Event1< Cia402FsmBase > &event, double timeoutSec=EVENT_DEFAULT_TIMEOUT_SEC, EventPriority priority=HIGH_PRIORITY_EVENT)

void addEvent (const Event2< Cia402FsmBase > &event, double timeoutSec=EVENT_DEFAULT_TIMEOUT_SEC, EventPriority priority=HIGH_PRIORITY_EVENT)

void addEvent (const Event3< Cia402FsmBase > &event, double timeoutSec=EVENT_DEFAULT_TIMEOUT_SEC, EventPriority priority=HIGH_PRIORITY_EVENT)

double getActiveTimeoutSec ()

virtual const char * eventName (Event< Cia402FsmBase > *event)

virtual EventStatus acknowledgeErrors ()

bool clearErrorMonitor (bool warnings_only=false)

ErrorHandleBase * getErrorMonitor ()

EventStatus warning (const Error &error)

EventStatus forcedDisengaged (const Error &error)

EventStatus shutdown (const Error &error)

EventStatus emergencyStop (const Error &error)

EventStatus delayEvent ()

virtual EventStatus terminateEvent ()

void errorMonitorAction ()

virtual void enter (int prev_state_id)

virtual void leave ()

virtual void leave (int next_state_id)


Additional Inherited Members

- Static Public Member Functions inherited from mcx::state_machine::State< Cia402FsmBase >
static int id (id_caller< STATE >)

- Protected Member Functions inherited from mcx::state_machine::State< Cia402FsmBase >
void addToEventList (const event_name &event)

void addEventName (const Event0< Cia402FsmBase > &event, const std::string &eventName)

void addEventName (const Event1< Cia402FsmBase > &event, const std::string &eventName)

void addEventName (const Event2< Cia402FsmBase > &event, const std::string &eventName)

void addEventName (const Event3< Cia402FsmBase > &event, const std::string &eventName)

- Protected Attributes inherited from mcx::drive::Cia402FsmBase
Cia402FsmData & fsm_data_

DriveMode drive_mode_ {DriveMode::DRIVE_MODE_NOMODE}

The documentation for this class was generated from the following files:
